Ozlux Products

Maintenance Free and low degradation: Because there is no filament or electrode, the life span amounts up to 80,000 hours. The average degradation rate is 15% in life time.

High efficiency and energy saving: High efficiency, it achieves ≥86 lm/W, the power factor is more than 0.98, cosφ≥0.98, lamp power consumption ≤ 0.02 input ≈output. High frequency electrode-less discharge lamp 100W is equiv to a 600W incandescent light. Under normal circumstances, a 85W high frequency electrode-less discharge lamp light output equals to 170W of Metal Halide, 250W of high pressure sodium, and 500W of incandescent.

Environmentally safe: It uses less than 3mg of encapsulated solid amalgam mercury. When the bulb breaks, it will not cause pollution. The lamp is 100% recyclable.

No flickering, low glare, good for eyes: Because of high efficiency, there is no flickering and the light is very stable and bright. It works unaffected by vibration and/or shaking.

High dependability: The product is available in both AC and DC models. The AC voltage is in the scope from 110V to 264V, 480V, and the DC in 12V or 24V. The operation temperature is between -40°F to +122°F.

Rapid start, no warm-up period: The function of start and restart is instant and it will not cause light degradation.

Techinical Data & Specification

Product Code	Watts	Voltage (Vac)	Power Factor	Bulb	Rated Avg. Life	Bulb Dimension LxWxH (mm)	Rated Avg. Life (Hrs) 1	Approx. Initial Lumens 2
OZILADX2S-62	120	240	≥0.95	Rectangle Tube	80,000	320 x 140 x 54	80,000	15,500

OZILAJX2S-62	150	240	≥0.95	Rectangle Tube	80,000	350 x 140 x 54	80,000	19,500

OZILBTX2S-62	200	240	≥0.95	Rectangle Tube	80,000	400 x 148 x 58	80,000	28,000

* Various system configuration is possible. Refer Product Naming Convention for details.
