Ozlux Products

Ozlux LEDFlood is a direct cost saving replacement for conventional outdoor floodlight. With its compact, different color temperatures and ruggedized enclosure, it is able to provide various uses for outdoor applications. While it uses LED illumination, there is no heat generated through it light source and has lower energy consumption. With LED technology, the lifespan is extended which provides minimal replacement.

EFFICIENT & DURABLE
• Replacement of Conventional Outdoor Floodlights
• Aluminium die-cast enclosure with toughened glass cover
• Long lifespan of 40,000 Hours

MULTI-APPLICATIONS

•	Various Colours suitable for Commercial Buildings, Showrooms, Store Display, Hotels and Restaurants
•	Wide operating temperature

TECHNICAL
• Natural Colour rendition
• No UV emissions
• Optimum Power Factor
• IP65 Enclosure

GREEN TECHNOLOGY
• Low energy consumption
• No mercury content
• Less heat dissipation

Techinical Data & Specification

Product Code	Description	Nom. Wattage (W)	Voltage (Vac)	Color Temp. (K)	Power Factor	Approx. Lumens (LM)	Approx. Lifespan (H)1	CRI	Beam Angle
OZEW10XBCBMAL	LEDFlood 10W	10	230	6500K	≥0.90	800	40,000	≥80	160±3°

OZEW30XBCBMAL	LEDFlood 30W	30	230	3000K	≥0.90	2400	40,000	≥80	160±3°

OZEW50XBCBMAL	LEDFlood 50W	50	230	595nm	≥0.90	4000	40,000	≥80	160±3°

OZEW80XBCBMAL	LEDFlood 80W	80	230	470nm	≥0.90	6400	40,000	≥80	160±3°

* Various system configuration is possible. Refer Product Naming Convention for details.
1 Approximate lifespan will be affected both by the LED package and transformer driver.
